TIG Welding

March 1, 2007
Tips and techniques for better welding

Tungsten inert gas (TIG) welding, also known as gas tungsten arc welding (GTA welding or GTAW), is often used in aircraft applications.

TIG welding provides a clean, strong weld joint that makes it ideal for assembling and repairing various aircraft components. In this article, we will discuss the basic theory of TIG welding and discuss some tips for better TIG welding results.

Basic Theory

In TIG welding, a non-consumable tungsten electrode is used to establish an arc on the base metal. The heat of the arc produced melts the base metal and produces a weld pool. In contrast to normal stick welding, when TIG welding, an inert gas shields the weld area in order to prevent air from contaminating the weld. This shielding gas prevents oxidation of the tungsten electrode, the molten weld puddle, and the heat-affected zone adjacent to the weld bead.

In a typical TIG setup, an AC/DC welding machine is used with a flow of shielding gas. The shielding gas goes through a regulator and flow meter and on to the torch. The torch has a collet/collet body combination that holds the electrode. A heat-resistant cup or ceramic nozzle surrounds the electrode and controls the gas shield. In addition, water-cooled TIG machines are available for high-amperage welding applications.

Personal Protective Equipment

Although TIG welding does not produce all of the metal spatter that is associated with stick welding, it still generates intense heat and light. In fact, the clearer atmosphere around the TIG arc can cause up to twice the amount of infrared and UV rays compared to normal arc welding.

Any exposed skin will be burned similar to an extreme sunburn. Welders should wear personal protective equipment such as a welding helmet, welder’s protective gloves, and clothing. Of course, fire-resistant cloth and leather clothing and accessories are recommended. A word of caution — cotton should not be used as it does not provide sufficient protection and it deteriorates quickly under the infrared and UV rays produced by the TIG welding process. As a tip, dark clothing should be used to reduce reflection of light behind the helmet.

Other Safety Precautions

The following general precautions should be observed to protect you and co-workers from the hazards associated with TIG welding:

Ensure electrical connection leads are in good condition and tight prior to use. They should be protected to prevent accidental damage from hangar traffic.

Make sure you have adequate ventilation. Since TIG welding uses inert gases to shield the weld area, if it is used in an enclosed area it can displace breathing air and can be hazardous. Ensure your work area has proper ventilation. In addition, ozone is produced during the welding process. Anyone who has been around a TIG welder knows the sweet smell associated with TIG welding. But high levels of ozone can be hazardous. The amount of ozone produced varies with the type of electrode used, amperage, and argon flow. In poorly ventilated areas, ozone levels can increase to irritating or harmful levels. Whenever possible, draw fumes and contaminated air away when welding.

Flammable materials should not be carried in clothing pockets. Shielding curtains should be placed around all jobs so that workers in adjacent areas are not exposed to the welding arcs.

Shielding Gas

In TIG welding, the gas used to shield the welding arc and hot metals is an inert gas. Inert gases are gases whose atomic structures do not allow them to react with metals or other gases. Argon, helium, or an argon-helium mixture is used as the inert gas in TIG.

Argon is a relatively heavy gas. It has several benefits when used in TIG welding. It requires a lower arc voltage than other shielding gases for a given arc length and current used (ideal for thin metal welding). It also provides easier arc starting. Its heavier weight as compared to helium provides for good shielding with lower flow rates.

In contrast to argon, helium is the lightest of the inert gases. Because of its light weight, about two to three times more helium is needed as compared to argon to shield the weld area. Despite this, helium has an advantage over argon in that it can be used with greater arc voltages.

Because of this, helium is preferred when working with thick metal sections.

Another difference in the two gases is their cleaning ability. Both helium and argon allow for good cleaning action when using DC. However, when using AC, argon provides for better cleaning action. Argon also provides better arc stability than helium when using AC.

Proper Gas Selection

You want to make sure to use the right gas with TIG. Usually, pure argon is used, although thicker welding may require an argon/helium or other specialty mix. If you use the wrong gas mixture, such as a 75 percent argon/25 percent CO2 that is common for MIG, the tungsten electrode will quickly be consumed or deposited in the weld puddle.

Gas Flow Rate

Setting a proper gas flow rate is another important element to successful TIG welding. Contrary to what may seem to be common sense, more isn’t better. If you are welding in a flat position, a flow rate of about 15 to 20 cubic feet per hour (cfh) is typically adequate. For overhead welding, you can start at about 20 cfh and increase the flow by small adjustments of about 5 cfh if necessary.

So why is too high a flow rate a bad thing? Well, if the gas flows out of the torch at too high a velocity, it ends up bouncing off the surface being welded and starts a swirling motion parallel to the torch cup called a venturi. This venturi effect will suck air into the gas flow, creating an impure weld atmosphere. This results in pinholes in the weld.


A TIG torch can either be air cooled or water cooled. If most of the welding you do is at 200 amps or less, an air-cooled torch is adequate. If welding above 200 amps, a water-cooled torch should be considered.

Controls are also offered in either foot pedal control or torch control. Foot pedal control tends to be more popular where work is done in an area that affords mobility. A fingertip control can be beneficial when working in an awkward position or where less mobility is available.


Many different electrode types are available including thoriated, lanthaniated, ceriated, and pure tungsten. When choosing an electrode, follow manufacturers’ recommendations and choose the one that is best for you. Some characteristics to consider in an electrode are good ignition and re-ignition properties, constant arc, long lifetime, and high current-loading capacity.

Good Welding Practices

You want to get in as comfortable a position as possible. Brace your arm to allow for steady torch movement. Many TIG welders hold the torch like a pencil to afford them the best control.

You want to hold the torch at the proper angle. If the torch is perpendicular to the work piece, it will be difficult to view the welding process.

The angle of the torch relative to perpendicular should be about 15 to 20 degrees. If this angle is exceeded too much, it can lead to less penetration, poor shielding gas coverage, and general arc instability.

In regards to travel direction, the torch should be pushed away from (ahead of) the weld puddle. This ensures proper gas coverage of the weld puddle and offers the welder a good view of the weld puddle.

Start Clean

Properly cleaning the area you will be welding is critical to a good weld result. Mike Sammons, sales and marketing manager for Weldcraft, points out, “Cleaning aluminum before GTA welding is essential to avoid contaminates, which can lead to lack of fusion, inclusions or porosity.” Be sure to wipe the base metal to remove any dirt, oil, grease or other contaminates.

Remove Oxides

When welding aluminum it is especially important to remove the oxides that naturally form on the surface. Aluminum oxide is the result of aluminum wanting to return to its natural state. Bare aluminum will oxidize as soon as it is exposed to the atmosphere, creating aluminum oxide.

Aluminum oxide is very hard (the only thing harder is a diamond). Its melting point is about three times that of aluminum. If not removed, it can lead to contaminated weld puddles or even prevent a weld puddle from properly forming.

Sammons discusses removing oxides from aluminum. “If you choose to remove the oxides mechanically, remember to designate the scraping tool or wire brush for that purpose only — using these tools for multiple jobs could cause contaminants to be introduced to the aluminum.

Using a power brush is not recommended as it can also re-embed contaminants into the metal. Finally, if you are considering using the chemical method to remove oxides, consult your local welding distributor for the best product options.”

Practice Makes Perfect

Although instruction manuals and magazine articles are a good place to get basic knowledge, the only way to become a better welder is to practice. And after you are done practicing, practice some more.

You need to be comfortable with your welding equipment. Practice welding on scrap metal. This is a good way to become familiar with the equipment you are using, allowing for more confidence when doing the actual welding.

Jim Brook, product manager for Miller, says that a good weld bead using filler resembles stacked dimes. “The weld will be of equal width with concentric circles, much like dimes stacked over each other in a row.”

When you start out, your weld beads may resemble plenty of things other than stacked dimes. Only through practice can you get consistent stacked dimes.
